PH-8

Phantoms for Medical Imaging

Lung Cancer Screening CT Phantom LSCT0001

Åpne stort bilde

LSCT0001 is a CT phantom developed to facilitate optimizing the radiation dose and other scanning conditions for Lung Cancer Screening CT examination with Helical CT or MDCT, which is aiming at early detection of lung cancers.
As the screening is usually done on healthy people, the necessity of minimizing the exposure while maximizing the image quality is considered to be particularly high.

The phantom is designed to set conditions for detection of small early lung cancers such as GGA, which are difficult to be found by plain X-ray. Anthropologic structure of the phantom provides life-like images allowing operators visual evaluation, while quantitative evaluation on radiation dose and density curve of the image can be done stimulatory with a single scanning.

Last ned produktbeskrivelse (PDF)



Produktegenskaper

Specifications

Phantom includes:

1 Chest Phantom: life size torso with arm up position

Internal structures:
  • Bones
  • Simulated tumors on sections of three lung area Apical portion of the lungs Bifurcation of the trachea Base of lungs
  • Dose meter hole (13 mm dia., on the central axis of the phantom) 1 8-step linearity phantom 8 steps of 30mm dia. density samples are embedded 1 adjustment base

Phantom size:

Chest Phantom:
Measurement around the chest 93 cm
Height 45 cm

Linearity phantom:
Diameter 200mm
Height 100 mm

Phantom weight:

Weight approx.18 kg

photo:

photo:








Teknisk informasjon

The classification of lung sounds is based on the criteria of the American Thoracic Society.

36 cases are available for training. 34 cases include 2 versions -- with and without heart-sounds
NORMAL standard FINE CRACKES both lower area
  mildly weak   both lower and middle area
  mildly strong   whole thorax 1
  mildly rapid   whole thorax 2
  loud heart sounds WHEEZES upper and middle area
ABNORMAL weak: left lower area   around trachea and upper area1
  weak: left whole area   around trachea and upper area2 (polyphone)
  absent: left RHONCHI trachea and upper area
  weak: right lower area   trachea and upper area (polyphonic)
  weak: right lower area   with an inspiratory wheeze
  absent right   whole thorax
  weak: whole thorax MISCELLANEOUS
CONTINUOUS SOUND		 stridor
  bronchial sounds   squawk
COARSE CRACKELS right lower area MISCELLANEOUS pleural friction rub: left lower area
  both lower area   pleural friction rub: right lower and middle area
  right middle area   Hamman's sign
  left lower area   Vocal fremitus (palpable at both sides of the chest)
  both upper area
  whole thorax

Components & Specifications

Component Qty Measurements Packing size Specifications
LSAT model unit 1 32 x 35 x 62H cm 51 x 46 x 80 cm 10 kg Torso with rotary base
15 built-in speakers
8 ch. amplifier
PC 1 59 x 59 x 40 cm 15 kg Windows XP, 12ch.D/A
PCI board,mouse,
112keyboard, 15"TFT monitor
*Software & data installed
Amplifier 1 32 x 35 x 8H cm 46 x 46 x 15 cm 10 kg AC 120-240V
Speakers 2 62 x 41 x 40 cm
20 kg (incl. monitor)
T-shirt 1 free size
